automatic iron soldering robot with spot soldering and drag soldering function

FOB Reference Price:Get Latest Price
US $3,500-4,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Other
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Topbest
Model Number:
Topbest-T-441R
Voltage:
220V
Current:
Alternating Current
Rated Capacity:
500w
Rated Duty Cycle:
50-100%
Dimensions:
815X600X880mm
Weight:
65kg (Net Weight)
Usage:
Soldering
Certification:
CE/ISO9001
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1year
X/Y/Z axis move speed (mm/sec):
X,Y 600-800MM / S ,Z 400MM/S
Processing scope(XYZR):
380*380*80MM,360°
Solder feeding speed:
1-50MM/S
Soldering feeding resolusion:
0.1MM
Repetitive Positioning Accuracy:
+/- 0.02 mm/ Axis
Heating power:
200W
Temperature control range:
0-550C°
Temperature control Accuracy:
+/-1C°
Air pressure requirement:
0.4 to 0.6MPa
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden Box Package
Port
Shen Zhen
Lead Time :
within 10-15 days
Product Description

Operation theory and Structure

Run mode:By application of multi-axis drive manipulator and software control to adapt atom positioning of the soldering head.
Soldering manner:Thermostatically heating by solder iron under high-frequency eddy current.
Working principle:Fix welding solder at the manipulator, move to the mission welding coordinate, feed solder wire automatically at head of solder iron; solder wire welds under high temperature and come into joint with the target
Dimension
815X600X880mm(L*W*H)/65KG
Working Range
380X380X80mm(X*Y*Z)
Working Temperature
5-40 degrees
Working Humidity
20-90% RH
Power Voltage
AC220V 50Hz
Heating Power
200W
X / Y / Z axis move speed (mm / sec)
 X, Y 600-800MM / S, Z 400MM / S
Repetitive Positioning Accuracy
+/- 0.02 mm / Axis
Temperature control range
0-550 degrees
Temperature Control Accuracy
± 1 degrees
Solder wire
0.4-1.2mm
Control Panel
 Teach pendant
Soldering Method
Point Soldering/Drag Soldering
Iron Tip Cleaning
Automatic air cleaning

Product Application

Suitable for automotive electronics, digital electronics, electronic, LCD, circuit boards and other production industries, connectors, RJ/network transformer, platoon line, FPCB welding, COF package for welding, computer motherboards, CABLE, speaker, and motor high-frequency head, photoelectric products and all high quality welding.

feature .

Cost saving:High-efficiency operation is achieved by only one person.one person's efficiency amounts to 3-5 persons' efficiency.
Good quality:Good soldering uniformity achieved high yield
High efficiency: Multiple soldering tips work together at the same time to achieve high efficiency.
More simple: One worker can operate 2-3 robots.what this worker does is only pick and place fixture.
Customization: Robot is strictly customized based on customers' requirements on products and soldering production,in line with requirements of production lines.
Good image: Intelligent automatic equipment presents a new appearance of production line in factories,which helps enterprises establish a image of high technology.

Our Certificate
Packing&Shipping
Our company

We have own factory and skilled workers,rich-experienced design team and good after service. We are a professional sales team with high efficiency, and endeavoring to provide satisfactory services to every of our customers as always.

Nearly every day from customers and abroad come to our factory, we will arrange technicians to show the machine operation. Free training is available. Warmly welcome you to visit our factory!

Customer visit
Related Products
FAQ

1.How about the package? Is it safe during the delivery?
All machine is packed by standard strong wooden carton with foam inside.

2. What is the delivery way? How many days will the machine?
We will ship the machine by DHL, Fedex, UPS, etc (Door to Door Service), around 5 days to arrive.Or by Air to your airport (Door to Airport Service), around 3 days to arrive. Or by Sea to the Seaport, Minium CBM requirement: 1 CBM, around 30days to arrive.

3. Do you provide the Warranty? How about the after sales service?
1 year warranty free for spare parts, Whole life technicial support.
We have professional after sales team, if any question, assistant videos are also provided in after-sale service.

4, This machine is easy to use? If I have no experience,  can I  also operate it well?
Do you provide the user manual and operating videos to support us?
Yes, our machine is designed to use easy, Normally it will take you 2-3 hours to learn how to operate, if you are a technician, it will much faster to learn.We will provide the English user manual for free, and the operation video is available.

5, If we come to your factory, will you provide the free training?
Yes, warmly welcome you to visit our factory, we will arrange the free training for you.

6. What is the payment way?
We accept the payment terms: Bank transfer, WesterUnion, Moneygram, Paypal, etc.

If any question, you can send INQUIRY, or CHAT us, we will be glad to service you!
