Handheld type electric auto feeding screwdriver machine

FOB Reference Price:Get Latest Price
US $1,200-1,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Topbest
Model Number:
Topbest-GW-4000S
Power Source:
Electricity
Type:
Multifuctional Screwdriver
Rated Voltage:
Auto feeder 12V,Screwdriver 20V/32V
Frequency:
50/60HZ
Rated Input Power:
Auto feeder 12W,Screwdriver 25W/55W
Max. Torque:
15kgf.cm / 1.5N.m
No-Load Speed:
1000r.p.m/2000r.p.m
Dimensions:
239*152*167mm
Weight:
4KG
Product Name:
Handheld electric Screwdriver Machine
Tighten efficiency:
60-80pcs/mins
Working temperature:
5-40℃
working humidity:
20-90% RH
Suitable for:
M1.2-M5 screw
Color:
Feature:
High Speed
Certification:
ISO9001/CE
Application:
Product assembly
Packing:
1SET/ Box
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden Box
Port
Shen Zhen
Lead Time :
within 7-10 days
Product Description

Hand-held type automatic feeder screwdrivers.

This machine is made of 3 main parts:
1.Screw feeding system.

2.Screw sorting system.

3.Screw fixing system.

These 3 systems are controlled by the machine's program.

The application of our handheld auto feeder screwdriver machine.

1.Scope of applicative screws: M1.2- M5,The total screw length≦16mm and screw head diameter≧2mm≦8mm
2.Scope of applicative screw heads: cross slot, triangle groove, trox, hexagonal slot, H head, .straight, etc
3.Surface Treatment of screw: electrolytic nickel plating, color zinc plating, white zinc plating, and copper plating, etc.
4.Screw materials: iron, copper, stainless steel, etc.
5.Materials of products to be screwed: plastic, iron, aluminum, etc.
6.Applicative Industries: mobile photo, hard disk, keyboard, toy, LCD/LED modules, communication equipment, electrical appliances, auto parts and so on.


Specifications.

Functions-Features

Features.

1.Portable Auto feeder screwdriver machine with small volume and can be carried conveniently.

2.Automatic feeding with vibration and Free-Fall Sensor,do not need air pressure feeding ,more simple and more convenient

3.LED display can display the number of fixing screws and can adjust feeding speed.

4. Sensor controls screws feeding one by one to avoid feeding repetition.

5.Automatic screw feeding, sorting and fixing for various shapes screws.One-hand operation.
6.Torsion precision and convenient adjustment, ensure the quality of screw fixing
7. High efficiency. No need to pick up screws, move screws and put screws. Just need to fix the screws aimed at the screw hole.
8. Can fix screws very fast, around fix 60 screws per minute.

Application cases
Certifications
Packing & Delivery
Company Information

We have own factory and skilled workers,rich-experienced design team and good after service. We are a professional sales team with high efficiency, and endeavoring to provide satisfactory services to every of our customers as always.
Nearly every day from customers and abroad come to our factory, we arrange technicians to show the machine operation. Free training is available. Warmly welcome you to visit our factory!

Related Products
FAQ

1.How about the package? Is it safe during the delivery?
All machine is packed by standard strong wooden carton with foam inside.

2. What is the delivery way? How many days will the machine?
We will ship the machine by DHL, Fedex, UPS, etc (Door to Door Service), around 5 days to arrive.Or by Air to your airport (Door to Airport Service), around 3 days to arrive. Or by Sea to the Seaport, Minium CBM requirement: 1 CBM, around 30days to arrive.

3. Do you provide the Warranty? How about the after sales service?
1 year warranty free for spare parts, Whole life technicial support.
We have professional after sales team, if any question, assistant videos are also provided in after-sale service.

4, Is this
 machine easy to use? If I have no experience,  can i also operate it well?

Do you provide the user manual and operating videos to support us?
Yes, our machine is designed to use easy, Normally it will take you 2-3 hours to learn how to operate, if you are a technician, it will much faster to learn.We will provide the English user manual for free, and the operation video is available.

5, If we come to your factory, will you provide the free training?
Yes, warmly welcome you to visit our factory, we will arrange the free training for you.

6. What is the payment way?
We accept the payment terms: Bank transfer, WesterUnion, Moneygram, Paypal, etc.


If any question, you can send INQUIRY, or CHAT us, we will be glad to service you!
